BREAKDOWN CODES
The breakdown codes are shown on the displays on the control panel.
Breakdown code Cause
E1, E2, E7 The temperature sensor is defective.
E3, E4 The glass plate sensor is defective.
The connection between the circuit boards
EU
is defective.
EL, EH The voltage is too low or too high.
The temperature of the glass plate sensor
C1, C2
is too high.
F5 The fan is defective.
EF Overflow error
ENERGY CONSUMPTION
Energy consumption for the hob calculated per kg
Energy consumption per cooking area calculated per kg
Energy consumption per cooking zone calculated per kg EC electric cooking
Energy consumption per cooking zone calculated per kg EC electric cooking
Energy consumption per cooking zone calculated per kg EC electric cooking
37
• English
Solution
Contact the Inventum service department.
Contact the Inventum service department.
Contact the Inventum service department.
Have your connection checked by an electrician.
Allow the glass plate to cool down and then switch
on the induction hob again.
Contact the Inventum service department.
Check if there is (cooking) water on the hob.
If so, clean and dry the hob.
Symbol Type
EC electric hob Hob
EC electric cooking Cooking area left
Cooking zone center
Cooking zone rear right
Cooking zone front right
Value
182,3 Wh/kg
191,5 Wh/kg
172,9 Wh/kg
183,8 Wh/kg
181,0 Wh/kg
