3
prior to first use
Before using the appliance for the first time, proceed as follows: carefully unpack the induction hob and remove all packaging
material. Keep the packaging (plastic bags and cardboard) out of reach of children. After unpacking the appliance, carefully
check it for external damage that may have occurred during transport. Clean the glass plate with a slightly damp cloth.
Check that the voltage corresponds with what is stated on the information plate. For installing the induction hob, observe the
instructions in the following section.
4
installation instruction
• Safety during use is only guaranteed if the assembly has taken place in a technically correct way and in accordance with
these installation instructions. The installer is liable for damage caused by incorrect assembly.
• The electrical connection may only be carried out only by a qualified electrician. This person should be aware of the national
and regional safety instructions that the connection has to comply with.
• The hob falls under protective class I and may only be used in combination with an earthed connection. The manufacturer
is not liable for unsuitable operation and possible damage caused by unsuitable electric installations.
• The hob must be connected to a permanent installation in which provisions for switching off are integrated, in accordance
with the installation instructions.
• Induction hobs may only be installed above a drawer, cabinet, an oven with forced ventilation or dishwasher, and always
with a minimum distance for ventilation. Under the induction hob, no refrigerators, ovens without ventilation or washing
machines should be installed.
• Make sure that the power supply cable does not get jammed during installation or is running along sharp edges. If an oven
is installed below it, make sure the cable runs via the rear corners of the oven to the connection box. It must be placed
in such a way that no contact is made with hot parts of the hob or oven.
• The connection point, socket and/or plug must always be accessible.
• The worktop on which the hob is placed must be flat, horizontal and stable. Observe the instructions from the
manufacturer of the worktop.
• In case of incorrect installation or connection, the warranty becomes invalid.
• Attention: any change to the appliance, including replacement of the power supply cable, must be performed
by a certified installer.
DIMENSIONS
Caution: The safety distance between the sides of the hob and the inner surfaces of the worktop must be at least 3 mm.
H
x
B
L (mm)
W (mm)
800
520
L
D
x
H (mm)
D (mm)
48
W
A
A (mm)
44
750 + 2
SEAL
x
F
Min. 3 mm
B (mm)
X (mm)
480 + 2
min. 50
English
F (mm)
min. 3
26
•
