NOTICE:
No need to tap the trimmer head to release
the cutting line. If you feel a slight tremor of the trimmer
head when trimming the grass, it is the cutting line being
automatically released.
WARNING:
Do not remove or alter the line-cutting
blade assembly. Excessive line length will cause the motor
to overheat and may result in serious personal injury.
LINE REPLACEMENT
NOTICE:
Only use the EGO nylon cutting line with
diameter 2.4mm. Using line other than that specified may
cause the line trimmer to overheat or become damaged.
WARNING: Never use metal-reinforced line,
wire, or rope, etc. These can break off and become
dangerous projectiles.
The line trimmer is equipped with an advanced
POWERLOAD system. The cutting line can be
TM
wound into the spool simply by pressing a single
button. Loading a full spool can usually be completed
in 15 seconds. Avoid repeated operation of the
winding system in rapid succession to reduce the
possibility of motor damage.
1. Remove the battery pack.
2. Cut 5 m long cutting line. Insert the line into the
eyelet (Fig. F). Push and pull the line from the other
side until equal amounts of the line appear on both
sides of the trimmer head.
NOTICE:
If the line cannot be inserted into the eyelet
when the lower cover is stuck, install the battery pack
onto the power head, then press the line-loading button
briefly to reset the lower cover.
3. Remove the battery pack if it has been installed
onto the power head in the NOTICE after step 2. And
follow the steps specified in step 2 to reinsert and
align the cutting line.
4. Install the battery pack onto the power head.
5. Press and hold the line-loading button to wind
the line into the trimmer head continuously until
approximately 15 cm of the line is showing on each
side (Fig. G).
NOTICE:
In case the line is pulled into the trimmer head
by accident, open the head and pull the cutting line out
from the spool. Follow the section "RELOADING THE
CUTTING LINE" in this manual to reload the line.
RELOADING THE CUTTING LINE
When the cutting line gets stuck in the trimmer head, you
will need to remove the remaining cutting line from the
trimmer head and follow the steps below to reload the line.
1. Remove the battery pack.
2. Press the release tabs on the trimmer head and
remove the lower cover assembly of the trimmer
head by pulling it straight out (Fig. H).
3. Remove the cutting line from the trimmer head.
4. With one hand holding the trimmer, use another hand
to grasp the upper cover and align the slots in the
upper cover with the release tabs. Press the lower
cover assembly until it snaps into place, at which
time you will hear a distinct click sound (Fig. I).
5. Follow the instructions in the "LINE REPLACEMENT"
section to reload the cutting line.
TRIMMER HEAD REPLACEMENT
WARNING:
If the head loosens after it is fixed in
position, replace it immediately.
Never use a trimmer with a loose cutting attachment.
Replace a cracked, damaged or worn out cutting head
immediately, even if damage is limited to superficial
cracks. Such attachments may shatter at high speed and
cause serious injury.
Familiarize yourself with the trimmer head (Fig. J).
J-1 Shaft J-3
J-2 Spool Assembly J-4
Remove the trimmer head
1. Remove the battery pack.
2. Press the release tabs on the trimmer head and
remove the lower cover assembly of the trimmer
head by pulling it straight out.
3. Remove the cutting line from the trimmer head
(Fig. K).
4. Wear gloves. Use one hand to grasp the spool
assembly to stabilize it, and use the other hand to
hold a 17 mm impact wrench (not included) to loosen
the lock nut in a CLOCKWISE direction (Fig. L).
5. Remove the lock nut and spool assembly from the
motor shaft (Fig. J).
6. Replace with a new trimmer head and mount it in
following steps.
Install the new trimmer head
1. Align the flat slot in the spool assembly with the flat
in motor shaft and mount the spool assembly into
place (Fig. M).
M-1 Flat M-2
LINE TRIMMER ATTACHMENT — STA1700
EN
Lock Nut
Lower Cover Assembly
Flat Slot
