FILTER PUMP INSTALLATION DISTANCE
(Generic layout of an electrical device relative to a swimming pool. Illustration not to scale)
According to the International Standard, IEC 60364-7-702, on electrical installation of swimming
pools and other basins equipment, the following installation distances must be respected:
• The filter pump must be positioned more than 2m away from the pool walls.
• The power cord plug to the 220-240 volt electrical power source of the filter pump must be
position more than 3.5 m away from the pool walls.
Check your local authorities to determine the appropriate standard and requirements for "electrical
installation of swimming pools and basins equipment". The following table is for reference only:
Country/Region
International
France
Germany
The Netherlands
FILTER PUMP STATIONARY MOUNTING
Some countries, especially in the European community, require the filter pump to be
secured to the ground or to a base in a permanent upright position. Check your local
authorities to determine if there is a regulation in your area regarding above-the-ground
swimming pool filter pumps. If yes, then the filter pump can be mounted to a platform
using the hole located in the base. See drawing below.
The filter pump can be mounted on a cement base or onto a wooden platform to prevent
accidental falling over. Total assembly must exceed 18kg.
SAVE THESE INSTRUCTIONS
(110) MODEL FP634 FILTER PUMP ENGLISH 7.5" X 10.3" PANTONE 295U 08/23/2024
hoses Electrical
device
POOL
>2m
1 x M4 HEXAGON HEAD BOLT/SCREW
>3.5m
Standard Number
IEC 60364-7-702
NF C 15-100-7-702
DIN VDE 0100-702
NEN 1010-702
110
English
A
Page 9
