ASA110H
Installation
Fig. 1: Mounting of the magnetic tape
Mounting examples
The simple mounting procedure by means of a beveled magnetic tape as
shown in
ments. In a non-protected environment there is the danger of peeling off.
Mounting approaches as shown in
such cases.
Optimum protection is provided by mounting in a groove as shown in
5. The groove should be deep enough so that the complete magnetic tape
will be embedded in it.
Fig. 2: Magnetic tape
beveled
Fig. 4: Magnetic tape screwed
from top
ASA110H · Date 01.10.2024 · Art. No. 84794 · Mod. status 111/24
5
6
4
1
Fig. 2
can only be recommended for very protected environ-
3
2
Fig. 3 Fig. 4
and are more suitable in
Fig. 3: Magnetic tape
screwed on the front
Fig. 5: Magnetic tape in groove
English 21
Fig.
