Documentation
1 Documentation
The following documents describe this product:
•
•
•
These documents can also be downloaded at
com/p/asa110h".
2 Safety information
2.1 Intended use
Combined with a magnetic strip MBA110/1 the translation module
ASA110H serves for determining a position value. The magnetic sensor is
only intended for use in industrial applications that are not subject to spe-
cial electrical or mechanical safety requirements.
1. Observe all safety instructions contained herein.
2. Arbitrary modifications and changes to this translation module are
3. Observe the prescribed operating and installation conditions.
4. Operate the translation module exclusively within the scope of techni-
2.2 Identification of dangers and notes
Safety notes consist of the signal symbol and a signal word.
Danger classes
Immediate danger that may cause irreversible bodily harm resulting in
DANGER
death, property damage or unplanned device reactions if you disregard
the instructions given.
Danger that may cause serious bodily harm, property damage or
WARNING
unplanned device reactions if you disregard the instructions given.
Danger that may cause minor injury, property damage or unplanned device
CAUTION
reactions if you disregard the instructions given.
ASA110H · Date 01.10.2024 · Art. No. 84794 · Mod. status 111/24
The data sheet describes the technical data, the dimensions, the pin
assignments, the accessories and the order key.
The installation instructions describe the mechanical and electrical
installation including all safety-relevant requirements and the associ-
ated technical specifications.
Software description of commissioning.
forbidden.
cal data and the specified limits (see chapter 8).
