(Optional) Secure Y our Powerline Network
1. Plug in your adapters.
2. Hold down the Pair button on an adapter for 1 second, and the PLC LED
on the adapter starts blinking.
3. Within 2 minutes, hold down the Pair button on the other adapter for 1 second.
Observe the PLC LEDs
LED & Button
LED Color
/
Green
/
Green
Red
/
Green
Button Description
Hold it down for about 1 second to start pairing.
Pair
Hold it down for about 6 seconds (the Power LED will be turned off and then turned on again)
to restore the adapter to factory settings.
on the two adapters until they light up and keep on.
Power LED
PLC LED
LAN LED
LAN Pair
Status Description
The device is not connected to a power supply.
Off
The device is powered on.
Solid on
The device is in power saving mode.
Slow blinking
The device is not paired with another powerline device, or is
Off
powered off.
Solid on The device is connected to a powerline network.
The device is pairing with a powerline device.
Fast blinking
The device is in poor condition. T ry changing another wall
Solid on
receptacle until the LED indicator turns green.
No Ethernet cable is detected on the Ethernet port.
Off
An Ethernet cable is connected properly.
Solid on
-3-
