DESCRIPTION OF PARTS (FIG. B)
1.
Flexible suction hose with spray tube
2.
Suction tubes
3.
Carpet and rug cleaning nozzle
4.
Upholstery cleaning nozzle
5.
Crevice nozzle
ASSEMBLY
1.
Open the top of the dirt tank, take out all components, and place the tank upside down
on flat surface.
2.
To properly assemble the caster, insert the metal pin into the designated spot on the
base of the body (Fig. 1). Press the caster until you feel resistance.
3.
Fasten the top cover by closing the plastic clamp (9, Fig. A).
4.
Insert the flexible suction hose with spray tube into the inlet opening (Fig. 2).
REMOVAL OF DRY DIRT AND DEBRIS
1.
To use the vacuum cleaner for removing dust and other dry debris, first place the HEPA
filter on the filter support, fasten the filter cover (Fig. 3), and then insert bag into the
vacuum cleaner at the inlet opening (Fig. 5).
2.
Fasten the top cover by closing the plastic clamp (9, Fig. A).
3.
Attach the flexible suction hose to the inlet opening (Fig. 2) and affix an appropriate
attachment. Make sure it is tightly fitted.
4.
To remove the attachment, just pull it off.
5.
Connect the power cord to the power source, and then turn on the vacuum cleaner by
pressing the switch (3, Fig. A).
6.
To regulate the air flow, turn the force control knob (4, Fig. A).
7.
To remove the HEPA filter, open the plastic clamps (9, Fig. A) and take off the top cover.
Next unfasten the filter cover, take out the HEPA filter from the filter support and remove
the bag from the inlet opening inside the vacuum cleaner.
8.
To connect the suction tubes, attach them to the flexible suction hose with spray tube
(Fig. 10). Ensure that they are firmly secured. To remove the suction tubes, press the
release button (a, Fig. 9) and pull.
9.
To attach the extension hose (9, Fig. B), secure it to the flexible suction hose with spray
tube (1, Fig. A). Ensure that it is firmly secured. To remove the extension hose, pull it out.
BLOWER FUNCTION
1.
To use the blower function place the HEPA filter on the filter support, fasten the filter
cover (Fig. 3), and then insert bag into the vacuum cleaner at the inlet opening (Fig. 5).
2.
Fasten the top cover by closing the plastic clamp (9, Fig. A).
3.
Attach the flexible suction hose to the outlet opening (5, Fig. A) and affix an appropriate
attachment. Make sure it is tightly fitted.
4.
To remove the attachment, just pull it off.
5.
Connect the power cord to the power source, and then turn on the vacuum cleaner by
pressing the switch (3, Fig. A).
6.
To regulate the air flow, turn the force control knob (4, Fig. A).
6.
Universal nozzle
7.
Dry vacuum cleaning bag
8.
Sponge filter
9.
Extension hose
10.
HEPA filter
