Quick Start
5. Remove the AC Power cord from the monitor. Connect the USB hub base power cord
to the monitor (Figure B.1) then connect the monitor's power cord, to the other USB
hub base power cord (Figure B.1).
6. Connect the other end of the monitor's power cord into the AC wall outlet (Figure C.1).
7. Connect the usb cable to the the usb output port of your computer system, and to the
USB Input Jack port on the back of the USB Hub Base.
8. Turn on the monitor (Figure D.1).
9. Turn on the Computer. The Computer should automatically recognize the USB Hub Base.
Follow the prompts given to complete the installation.
USB Output
Figure D.1
FP955.wpc
–continued
Figure B.1
Figure C.1
Power Button
4
6
AC IN
Monitor
Power Cord
