12. Repairs
Repairs to electrical tools must be carried out
by qualified electricians ONLY!
If you have Metabo electrical tools that require
repairs, please contact your Metabo service centre.
For addresses see www.metabo.com.
A defective mains cable must be replaced only with
a special, original mains cable from Metabo
available from the Metabo service.
You can download spare parts lists from
www.metabo.com.
13. Environmental Protection
The sanding dust generated may contain
hazardous materials: do not dispose of with the
household waste, but at a special collection point
for hazardous waste.
Observe national regulations on environmentally
compatible disposal and on the recycling of disused
machines, packaging and accessories.
Packaging materials must be disposed of according
to their labelling in accordance with municipal
guidelines. Further information can be found at
www.metabo.com in the "Service" section.
Only for EU countries: Never dispose of
power tools in your household waste! In
accordance with European Guideline 2012/
19/EU on used electronic and electric equipment
and its implementation in national legal systems,
used power tools must be collected separately and
returned for environmentally compatible recycling.
Special instructions for cordless machines:
Battery packs must not be disposed of with regular
waste. Return faulty or used battery packs to your
Metabo dealer!
Do not allow battery packs to come into contact with
water!
Before disposal, discharge the battery pack in the
power tool. Prevent the contacts from short-circu-
iting (e. g. by protecting them with adhesive tape).
14. Technical specifications
Explanation of details on page 3. Subject to
changes serving technical progress.
U
= Voltage of battery pack
D
= max. diameter of accessory
max
t
= Max. permitted thickness of clamping
max,1
shank on accessory when using
clamping nut (20)
t
= max. permitted thickness of clamping
max,2
shank on accessory when using
"Quick"clamping nut (2)
t
= Roughing wheel/cut-off wheel:
max,3
max. permissible thickness of the
accessory tool
t
= max. permitted thickness of wheel-
max,4
type wire brushes
M
= Spindle thread
l
= Length of the grinding spindle
n
*
= No-load speed (maximum speed)
0
P
= Nominal power input
1
P
= Power output
2
m
= Weight with smallest battery pack/
weight without cord
Measured values determined in conformity with
EN 62841.
Machine in protection class II
~
Alternating current
Direct current
The technical specifications quoted are subject to
tolerances (in compliance with the relevant valid
standards).
Electromagnetic disturbances:
In individual cases, the speed may fluctuate tempo-
rarily if the machine is exposed to extreme external
electromagnetic disturbances or the electronic
restart protection may respond. In this case, switch
the machine off and on again.
Emission values
Using these values, you can estimate the
emissions from this power tool and compare these
with the values emitted by other power tools. The
actual values may be higher or lower, depending on
the particular application and the condition of the
tool or power tool. In estimating the values, you
should also include work breaks and periods of low
use. Based on the estimated emission values,
specify protective measures for the user - for
example, any organisational steps that must be put
in place.
The grinding of thinner metal sheets and other
workpieces with large surfaces that easily
vibrate can lead to a significantly higher overall
sound emission (up to 15 dB) than the sound
emission values specified. The sound radiation of
such workpieces should be prevented to the
greatest extent possible by means of suitable
measures, such as fitting heavy, flexible damping
mats. The increased sound emission must also be
taken into account when assessing the risk of noise
exposure and selecting suitable hearing protection.
Vibration total value (vector sum of three directions)
determined in accordance with EN 62841:
a
= Vibration emission value
h, SG
(surface grinding)
a
= Vibration emission value
h, DS
(disc sanding)
K
= Uncertainty (vibration)
h,SG/DS
Typical A-effective perceived sound levels::
L
= Sound pressure level
pA
L
= Acoustic power level
WA
K
, K
= Uncertainty
pA
WA
During operation the noise level can exceed
80 dB(A).
Wear ear protectors!
