VII. PREPARATION FOR OPERATION
1. The BLANCONE
around the patient and the dental unit. See the positioning examples (Section X).
The bleaching head must be in the same vertical plane and parallel with the arc of the teeth with
a distance between 5-15 cm. See the positioning examples (Section X).
2. Plug the power adapter into the power network. Only one point/dot on the
display lights up. Press START / STOP button and then the "Hi" (High) or "Lo"
(Low) intensity indication appears.
3. The display shows "HI" - a high intensity level. If you want to switch to the "Lo"
(Low) intensity mode, press the TIMER / MODE (+ / -) button once. Then the
display will show "Lo". Every time before setting the required time, you will be
able to select the Hi or Lo intensity level.
4.
Press the START / STOP button once again and set time option will be dis-
played. Note that the device will save the time frame used in the latest bleach-
ing procedure. Required timeframe for operation is set by pressing TIMER +
(increasing time) and TIMER- (reducing time):
The display on the bleaching head will indicate timeframes between 10 sec.
and 9 min. and 50 sec. with a dot between the two digits.
Examples:
Display indicates: 13. This means the timeframe is set to 13 min.
Display indicates: 0.1. This means the timeframe is set to 10 sec.
Display indicates: 9.5. This means the timeframe is set to 9 min. and 50 sec.
The display on the bleaching head will indicate timeframes between 10 min.
and 30 min. without a dot between the two digits.
5. Press the START / STOP button one final time and the device will start to emit light. A flashing dot on
the display will indicate that the device is working properly.
6. If either of the TIMER / MODE (+ / -) buttons is
pressed during operation, the unit switches to
Pause mode. A blinking display with the remaining
time will indicate that the device is paused. Oper-
ation is resumed by pressing any TIMER / MODE
(+ / -) button again.
7. To Stop the bleaching device at any time press the
START / STOP button. If the device is not manu-
ally stopped it will stop after the selected time has
elapsed. Note that the fan will continue to work for
some time in order to cool down the unit.
12
Dental LED bleaching activation unit - MOBILE
ARCUS bleaching activation device should be placed in a suitable position
+
®
