min. 5 x 0.5 mm to 0.75 mm
(5 x 21 AWG to 19 AWG)
m a x .
6 ( 0 .
2 4 )
4 0 ( 1
. 5 7 )
mm (in)
INPUT
B1 B2 B3 B4
A1 A2 A3 A4
1 1
1
2
2 2
2 0 0
m ( 6 5
6 f t )
2
B
A
B1 = 24 V
B2 = digital input 1
B3 = digital input 2
B4 = digital input 3
A1 = 24 V
A2 = digital input 4
A3 = digital input 5
A4 = digital input 6
3
B
A
MD-IO-41-IS-xx-10
B
A
