Assembly Instructions
STEP 6
Installing Seat to the Main Frame
CAUTION
The Seat Stop MUST be in
the locked position whenever
the seat is in
use..
WARNING
Do not under any
circumstances attempt to
remove / install Seat while
occupied.
a) Seat Stop: Must be lowered to allow Seat onto
Baseplate Track. Must ALWAYS be in the LOCKED
position when Seat is occupied on Baseplate. Must be
lowered to allow Seat removal. To LOCK, raise and
locate. To UNLOCK, lift and drop rearward.
b)
Seat Installation: Tilt the Seat slightly upward to allow
the front Rollers to engage the channel. Then, lift the
rear level and, while engaging the Seat Lock Release
Lever, slide the Seat onto the Baseplate as shown.
Usage: The Seat has four positions. To move forward
or rearward, depress the Seat Lock Release Lever
and move freely to whichever position you require.
c)
To remove the Seat: Lift and lower the Rear Safety lock,
depress the Seat Lock Release Lever and slide the seat
rearward.
12
