PITCH BENDER/MODULATION
By moving the Pitch Bender/Modulation lever [8], bending can be obtained. Moving the lever to the right
raises the pitch and moving the lever to the left lowers the pitch of the note. If the lever is released
(central position), the note returns to normal pitch. This lever canbe used to give a guitar bending effect
or the sliding of the trombone.
Pushing the same lever away from you will add modulation (vibrato/tremolo) to each tone. Releasing
the lever will cancel the modulation
OCTAVE [3]
UP:
DOWN:
STANDARD:
OCTAVE «UP»
Pressing the «UP» button, the PC-200 will be transposed of twelve semitones (one octave) up and the
keyboard sounds from C8 (48) to 07 (96).
OCTAVE «DOWN»
Pressing the «DOWN» button, the PC-200 will be transposed of twelve semitones (one octave) down
and the keyboard sounds from Cl (24) to C5 (72).
STANDARD:
Pressing both buttons, the original octave will be reset (default), and the keyboard will sound from C2
(36) to C6 (84).
MIDl CHANNEL SELECTION:
To select MIDI channels 1-16 (transmission):
— Press the MIDI/SELECT button [21,the corresponding led will light. Now the keyboard is disabled,
as it is programming.
Select anyone of the 16 Midi Channels [5] by pressing one of the following keys:
tx midi ch
1
— tx midi ch 2
tx midi ch 3
— tx midi ch 4
= tx midi ch 5
= tx midi ch 6
tx midi ch
tx midi ch
8
G # 2 = tx midi ch 9
tx midi ch 10
tx midi ch
11
= tx midi ch 12
tx midi ch
13
tx midi ch
14
tx midi ch 15
tx midi ch
16
Pressing the MIDI/SELECT
the keyboard will be enabled to play again.
LEVER
effect.
button once more, the corresponding led will be turned off and
9
