Rated insulation voltage U
i
Rated impulse withstand voltage U
Overvoltage category
Degree of pollution
Données électriques
Operating voltage
No-load supply current I , typical
0
Current consumption magnet at switching moment, peak
Rated operating voltage
Operating current
Required rated short-circuit current
External wire and device fuse rating
Time to readiness, maximum
Switching frequency, maximum
Utilisation category DC-12
Données électriques - Commande de l'électroaimant IN
Designation, Magnet control
Switching thresholds
Magnet switch-on time
Test pulse duration, maximum
Test pulse interval, minimum
Classification ZVEI CB24I, Sink
Classification ZVEI CB24I, Source
Current consumption at 24V, minimum
Current consumption at 24V, maximum
Données électriques - Entrées de sécurité tout-ou-rien
Designation, Safety inputs
Switching thresholds
Current consumption at 24 V
imp
32 VDC
0,8 kV
III
3
24 VDC -15 % / +10 %
100 mA
600 mA / 100 ms
24 VDC
1 200 mA
100 A
2 A gG
4 000 ms
0,25 Hz
24 VDC / 0,05 A
IN
-3 V ... 5 V (Low)
15 V ... 30 V (High)
100 %
5 ms
40 ms
C0
C1
C2
C3
10 mA
15 mA
X1 and X2
−3 V ... 5 V (Low)
15 V ... 30 V (High)
5 mA
