Actuating speed, maximum
Mounting
Type of the fixing screws
Tightening torque of the fixing screws, minimum
Données mécaniques - Distances de commutation selon EN IEC 60947-5-3
Assured switching distance "ON" S
Assured switching distance "OFF" S
Données mécaniques – technique de connexion
Length of sensor chain, maximum
Note (length of the sensor chain)
Note (series-wiring)
Termination
Données mécaniques - Dimensions
Length of sensor
Width of sensor
Height of sensor
Conditions ambiantes
Degree of protection
Ambient temperature
Storage and transport temperature
Relative humidity, maximum
Note (Relative humidity)
Resistance to vibrations
Restistance to shock
Protection class
Permissible installation altitude above sea level, maximum
Conditions ambiantes - Valeur d'isolation
ao
ar
0,5 m/s
Trous de fixation boîtier fraisé
2x M5
4 Nm
1 mm
8 mm
30 m
Cable length and cross-section change the voltage drop dependiing
on the output current
Unlimited number of devices, oberserve external line fusing, max. 31
devices in case of serial diagnostic SD
Connecteur M12, 8 pôles, codage A
119,5 mm
40 mm
20 mm
IP67
IP66
+0 ... +55 °C
-40 ... +85 °C
93 %
sans condensation
non givrant
10...55 Hz, amplitude 1 mm
30 g / 11 ms
III
2 000 m
7-29
