INSTRUCTIONS FOR OPERATION AND ASSEMBLY
Solenoid interlock AZM40Z-ST-1P2P (Test)
Table of Contents
1 About this document
1.1 Function
1.2 Target group of the operating instructions: authorised qualified personnel
1.3 Explanation of the symbols used
1.4 Appropriate use
1.5 General safety instructions
1.6 Warning about misuse
1.7 Exclusion of liability
2 Product description
2.1 Ordering code
2.2 Special versions
2.3 Purpose
2.4 Technical Data
3 Mounting
3.1 General mounting instructions
3.2 Manual release
3.3 Dimensions
4 Electrical connection
4.1 General information for electrical connection
4.2 Anforderungen an eine nachgeschaltete Auswertung
4.3 Wiring configuration and connector accessories
4.4 Wiring examples
5 Active principle and diagnostic functions
5.1 Magnet control
5.2 Mode of operation of the safety outputs
5.3 Diagnostic-LEDs
5.4 Diagnoseausgänge
5.5 Diagnoseinformationen
6 Actuator teaching / actuator detection
7 Set-up and maintenance
7.1 Functional testing
7.2 Maintenance
8 Disassembly and disposal
8.1 Disassembly
8.2 Disposal
1 About this document
1-25

Werbung

loading

Inhaltszusammenfassung für schmersal AZM40Z-ST-1P2P

  • Seite 1 INSTRUCTIONS FOR OPERATION AND ASSEMBLY Solenoid interlock AZM40Z-ST-1P2P (Test) Table of Contents 1 About this document 1.1 Function 1.2 Target group of the operating instructions: authorised qualified personnel 1.3 Explanation of the symbols used 1.4 Appropriate use 1.5 General safety instructions 1.6 Warning about misuse...
  • Seite 2 Warning:Failure to comply with this warning notice could lead to physical injury and/or damage to the machine. 1.4 Appropriate use The Schmersal range of products is not intended for private consumers. The products described in these operating instructions are developed to execute safety-related functions as part of an entire plant or machine.
  • Seite 3 The user must observe the safety instructions in this operating instructions manual, the country specific installation standards as well as all prevailing safety regulations and accident prevention rules. Further technical information can be found in the Schmersal catalogues or in the online catalogue on the Internet: products.schmersal.com.
  • Seite 4 without Standard coding Individual coding Individual coding, re-teaching enabled without Counterbores for countersunk screws (standard) Flat enclosure for protruding screws Betätiger AZM40-B1   AZM40-B1-PH 2.2 Special versions For special versions, which are not listed in the ordering code, these specifications apply accordingly, provided that they correspond to the standard version.
  • Seite 5 gemäß den technischen Daten, begrenzt. The user must evaluate and design the safety chain in accordance with the relevant standards and the required safety level. If multiple safety sensors are involved in the same safety function, the PFH values of the individual components must be added. The entire concept of the control system, in which the safety component is integrated, must be validated to the relevant standards.
  • Seite 6 Manual release Short circuit detection Cross-circuit detection Series-wiring Safety functions Integral system diagnostics, status Number of safety contacts Safety classification Standards EN ISO 13849-1 EN IEC 61508 Safety classification - Interlocking function Performance Level, up to Category PFH value 1.10 x 10⁻⁹ /h PFD value 8.90 x 10⁻⁵...
  • Seite 7 Latching force 40 N Note (Latch force) +/- 25% Actuating speed, maximum 0.5 m/s Mounting mounting holes countersink Type of the fixing screws 2x M5 Tightening torque of the fixing screws, minimum 4 Nm Mechanical data - Switching distances according EN IEC 60947-5-3 Assured switching distance "ON"...
  • Seite 8 Permissible installation altitude above sea level, maximum 2,000 m Ambient conditions - Insulation values Rated insulation voltage U 32 VDC Rated impulse withstand voltage U 0.8 kV Overvoltage category Degree of pollution Electrical data Operating voltage 24 VDC -15 % / +10 % (stabilised PELV power supply) 24 VDC -15 % / +10 % (stabilisiertes PELV-Netzteil) No-load supply current I , typical...
  • Seite 9 Designation, Safety inputs X1 and X2 Switching thresholds −3 V … 5 V (Low) 15 V … 30 V (High) Current consumption at 24 V 5 mA Test pulse duration, maximum 1 ms Test pulse interval, minimum 100 ms Classification ZVEI CB24I, Sink Classification ZVEI CB24I, Source Electrical data - Safety digital outputs Designation, Safety outputs...
  • Seite 10 This device complies with the nerve stimulation limits (ISED SPR-002) when operated at a minimum distance of 100 mm. Changes or modifications not expressly approved by K.A. Schmersal GmbH & Co. KG could void the user's authority to operate the equipment.
  • Seite 11 This device complies with the nerve stimulation limits (ISED CNR-102) when operated at a minimum distance of 100 In the event of changes or modifications that have not been expressly approved by K.A. Schmersal GmbH & Co. KG, the user's authorisation to use the device may become ineffective.
  • Seite 12 The actuator must be permanently fitted to the safety guards and protected against displacement by suitable measures (tamperproof screws, gluing, drilling of the screw heads). Der Einsatz des Sicherheitsschalters bei Minustemperaturen ist nur bei trockener Kälte erlaubt. Dies ist kundenseitig bei der Montage des Sicherheitsschalters zu berücksichtigen.
  • Seite 13 Justage Die beiden M4-Innensechskantschrauben erlauben eine Justierung der Betätigerzunge in X-Richtung mit Hilfe eines Innensechskant-Schlüssels SW 2 mm. Justage über M4-Innensechskantschrauben Die Innensechskantschrauben dürfen nicht komplett herausgedreht werden. Betätigungsrichtungen Der Betätiger lässt sich stufenlos um 180° einführen. 13-25...
  • Seite 14 Um eine systembedingte Beeinflussung und eine Reduzierung der Schaltabstände zu vermeiden, bitte folgende Hinweise beachten: Metallteile und Magnetfelder in der Nähe des Betätigers und der Sicherheitszuhaltung können den Schaltabstand beeinflussen oder zu Funktionsstörungen führen Metallspäne fernhalten. Mindestabstand zwischen AZM40 Sicherheitszuhaltungen All measurements in mm.
  • Seite 15 Hilfsentriegelung in die Ausgangslage ist die normale Funktion wieder gegeben. Hilfsentriegelung nicht über den Anschlag hinaus drehen. Zur Betätigung der Hilfsentriegelung ist ein Werkzeug (Empfehlung: Schlitzschraubendreher 0,8 x 4 … 4,5 mm) notwendig. The manual release must be protected against accidental actuation, e.g. by using the enclosed seal after completing commissioning.
  • Seite 16 4 Electrical connection 4.1 General information for electrical connection The electrical connection may only be carried out by authorised personnel in a de-energised condition. The voltage inputs A1, X1, X2 and IN must have a protection against permanent overvoltage. Supply units according to EN 60204-1 is recommended.
  • Seite 17 Information for the selection of suitable safety-monitoring modules can be found in the Schmersal catalogues or in the online catalogue on the Internet: products.schmersal.com. 4.3 Wiring configuration and connector accessories Funktion     Pinbelegung Farbcodes der Schmersal- Mögl. Farbcode Sicherheitsscha...
  • Seite 18 Connecting cables with coupling (female) IP69K, M12, 8-pole - 8 x 0,21 mm² Cable length Ordering code 5,0 m 101210560 5,0 m, angled 101210561 10,0 m 103001389 15,0 m 103014823 Weitere Ausführungen in anderen Längen und mit gewinkeltem Leitungsabgang auf Anfrage erhältlich. Bei Einsatz eines Winkelsteckers ist dieser parallel zur Befestigungsfläche ausgerichtet und zeigt zur Betätiger abgewandten Seite.
  • Seite 19 5 Active principle and diagnostic functions 5.1 Magnet control Die bistabile Zuhaltung wird durch das betriebsmäßige Setzen des IN Signals (= 24 V) entsperrt. Wird das IN Signal nicht gesetzt (= 0 V) geht die Sicherheitszuhaltung in den gesperrten Zustand, sofern der korrekte Betätiger in die Sicherheitszuhaltung eingeführt ist.
  • Seite 20 yellow (Status) Operating condition red (Fault) Error (see table 2: Error messages / flash codes red diagnostic LED) The green LED indicates that the safety sensor is ready for operation. The supply voltage is on and all safety inputs are present.
  • Seite 21 Ablauf, Sperrsignal wird nach dem Schließen der Tür angelegt Ablauf, Sperrsignal wird vor dem Schließen der Tür angelegt Gestörter Ablauf, Tür konnte nicht gesperrt werden oder Fehler Legende Sperren Entsperren Sperrzeit     Tür geöffnet Tür geschlossen         ...
  • Seite 22 Tabelle 1: Diagnoseinformationen des Sicherheitsschaltgerätes Systemzusta Magnetanste Sicherheitsausgänge Diagnoseaus uerung Y1, Y2 gang (bistabil)     grün gelb AZM40Z AZM40B   Tür auf 24 V Tür 24 V blinkt 24 V 24 V geschlossen, nicht gesperrt Tür blinkt blinkt 24 V geschlossen, Sperrung nicht möglich...
  • Seite 23 Tabelle 2: Fehlermeldungen / Blinkcodes rote Diagnose-LED Blinkcodes (rot) Bezeichnung eigenständige Fehlerursache Abschaltung nach 1 Blinkpuls Fehler(-warnung) an Ausgang Y1 30 min Fehler im Ausgangstest oder Spannung am Ausgang Y1, obwohl der Ausgang abgeschaltet ist 2 Blinkpulse Fehler(-warnung) an Ausgang Y2 30 min Fehler im Ausgangstest oder Spannung am Ausgang Y2,...
  • Seite 24 7 Set-up and maintenance 7.1 Functional testing Das Sicherheitsschaltgerät ist hinsichtlich seiner Sicherheitsfunktion zu testen. Hierbei ist vorab Folgendes zu gewährleisten: 1. Unversehrtheit der Leitungsanschlüsse prüfen. 2. Schaltergehäuse auf Beschädigungen überprüfen. 3. Entfernen von Schmutz. 7.2 Maintenance Bei ordnungsgemäßer Installation und bestimmungsgemäßer Verwendung arbeitet das Sicherheitschaltgerät wartungsfrei.
  • Seite 25 £ legislations. 25-25 Schmersal, Inc., 15 Skyline Drive, Hawthorne, NY 10532 The details and data referred to have been carefully checked. Images may diverge from original. Further technical data can be found in the manual. Technical amendments and errors possible.
