Mechanical Installation
Installing the 710W Spindle
Spindle module needs to be prepared by yourself.
1. Using a 3mm Allen wrench, loosen the 2 screws on the spindle motor mount and install the spindle.
2. Separately lock the 2 screws on the spindle motor mount and the 4 screws on the side.
(Note: With the upgraded XZ-axis module, you can only use 710W spindle or other compact router.)
(2) Screw on the Spindle Motor Mount
(4) M5×14 Socket Head Cap Screw
12
