5� Connect the RTK Reference Station power cable to the Charging
Station power cable and tighten the nut�
A B
Note: The Charging Station has two cable ports: the longer one is for the Power
Adapter and the short one is for the RTK Reference Station�
6� After powering on, please wait one minute to check the indicator light
status� If the RTK Reference Station indicator remains steady blue,
the location is ideal with good signal; if it flashes, relocate the RTK
Reference Station, until you find the perfect position�
7� After locating the perfect spot, insert the RTK Station Fixing Fork Peg
into the ground�
Note:
•
DO NOT install the RTK Reference Station to a spot where the ground is soggy
and mushy, otherwise the pole may easily tilt, thus undermining the working accu-
racy of the RTK Reference Station�
•
The RTK Reference Station should be oriented vertically, as shown below:
