Bottom View; Back View - Ecovacs Goat O800 Rtk Betriebsanleitung

2

Bottom View

Back View

3
EN 14
Rear Wheels
(O800 RTK)
Off-road Wheels
(O1200 RTK)
Battery Compartment
Blades
Blade Disc
Front Wheels
4 Charging Station and RTK Reference Station
RTK Reference Station
RTK Indicator Light
Station Indicator Light
Charging Station
Charging Station Light
Solid Blue: Powered on/ Fully charged�
Flashing Blue: Charging�
RTK Reference Station Light
Solid Blue: Strong signal�
Flashing Blue: Poor signal� Please select a new location for installation�
