Before using for the first time
1*
Figure
Push the handle onto the flexible tube and until it
engages.
Setting up
2
Figure
a) Push the hose connector into the opening on the vacuum
cleaner until it engages.
b) To remove the flexible hose, press the two lugs together
and pull the hose out.
3*
Figure
Connect the handle and the suction pipe together.
4*
Figure
a) Connect the floor tool and the suction pipe together.
b) Insert the telescopic tube into the floor tool connector.
5*
Figure
a) Connect the suction pipes together.
b) Disconnect the telescopic tube and adjust its length by
moving the adjusting button/sliding sleeve in the
direction of the arrow.
6
Figure
Holding the power cord by the plug, pull out the required
length and plug it into the mains socket.
7
Figure
Press the on/off button in the direction of the arrow to
switch your vacuum cleaner on/off.
8
Figure
Adjust the suction by turning the on/off button in the
direction of the arrow.
Vacuuming
9
Figure
Adjusting the floor tool:
a) Rugs and carpets
b) Hard floors
Caution!
Floor tools are subject to a certain amount of wear,
depending on the type of hard floors you have
(e.g. rough, rustic tiles). Therefore, you must check
the underside of the floor tool at regular intervals.
Worn undersides of floor tools may have sharp edges
that can damage sensitive hard floors, such as parquet
or linoleum. The manufacturer does not accept any
responsibility for damage caused by worn floor tools.
* Depending on equipment
Figure
b) Corner nozzle
c) Upholstery nozzle
e) Hard floor nozzle
Figure
Figure
When the work is done
Figure
Figure
You have purchased a floor vacuum cleaner which can
vacuum up any type of dry dirt using the dust collector or
dust bag.
We recommend that you use:
- the dust collector, in particular for your hobbies, e.g. to
- the dust bag principally for everyday household cleaning.
Using the dust collector
=>
=>
Figure
!
10*
Vacuuming with accessories
(connect to the handle or the suction hose as required)
For vacuuming in corners and joins
For vacuuming upholstery, curtains etc.
For vacuuming hard floor surfaces (tiles, parquet etc.)
11
You can use the parking aid on the back of the vacuum
cleaner if you wish to stop vacuuming for a short time.
Slide the catch on the floor tool into the groove at the
rear of the appliance.
12
The appliance can also be carried using the two handles
when vacuuming steps, for example.
13
Unplug the vacuum cleaner.
Tug the power cord briefly and let go. The cable then
rewinds automatically.
14
To store or transport the vacuum cleaner, use the storage
aid on the underside of the vacuum cleaner.
Stand the vacuum cleaner up on its end. Slide the catch
on the floor tool into the groove on the underside of the
appliance.
remove wood shavings, etc.
15
Set the power setting to maximum for the best results
when vacuuming.
We recommend that you reduce the setting only when
vacuuming very delicate materials.
Attention: The dust bag change indicator only
functions correctly in conjunction with a dust bag.
