3. Please proceed according to the following LED status
messages:
Status
Meaning
"Correct" LED
Vehicle battery
"Correct" LED
is OK and can
lights up green
be started.
The state of
"Correct" LED
charge of the
flashes green
vehicle battery
is very low.
Terminals are
Red LED lights
connected
up
with reversed
polarity.
Note: If all existing connections are OK and no LED lights
up, the cause is probably a faulty vehicle battery. Replace
the faulty vehicle battery as soon as possible.
4. As soon as the engine is running, remove the terminals
from the battery. Note: first remove the black terminal
and then the red terminal.
5. Leave the engine running as the alternator recharges
the installed vehicle battery. At very low temperatures,
it may be necessary to make several attempts to start
the engine.
The waiting time between two start attempts should be at
least one minute. The maximum number of possible
jump-start attempts should not exceed 4 within
10 minutes.
If too many start attempts have been made in succession,
the 'Correct' LED will alternate between red and green and
no further start attempts can be made. After waiting for
20
Application
If additional starting
support is required, press
the 'Boost' button twice
in succession with a time
delay of at least 1 second.
The vehicle can be started
within 30 seconds.
Press the 'Boost' button
1×, The vehicle can be
started within 30 seconds.
Connect the terminals
with the correct polarity.
10 minutes, the jump-start function is available again,
provided there is still sufficient battery capacity and the
integrated safety device allows it.
OUTPUTS AND FUNCTIONS
2x USB-A output 5 V/2.4 A: Connect the end device to be
charged to the ANSMANN jump starter using the USB cable
supplied. Then press the on/off switch
1x USB type C input 5 V/3 A: Connect the
ANSMANN jump starter to a USB power adapter with the
supplied USB cable and the charging process starts
automatically.
Jump leads adapter: The jump leads included in the scope
of delivery are connected via the jump leads connection.
Rechargeable battery capacity indicator::
• 100% capacity = 4 LEDs light up
• 75% capacity = 3 LEDs light up
• 50% capacity = 2 LEDs light up
• 25% capacity = 1 LED lights up
Torch function: Press and hold the on/off switch for 3 se-
conds to switch on the LED. Press again to switch on the
strobe light and press again to switch on the SOS function.
TECHNICAL DATA
Battery:
LiPo 10000 mAh/37 Wh
Input:
USB-C: 5V DC/3 A/15 W
Output:
USB-A1/USB-A2: 5.0 V/2.4 A/12.0 W
12 V jump starter: 400 A ( 1500 A max.)
