EN
MSGS-200 EVO |
11. NOZZLE TIP CLEANING
1
2
12. CLEANING AND MAINTENANCE OPERATIONS
WARNING
FULLY CLEAN AFTER EACH USE TO ENSURE LONGER LIFETIME OF THE SPRAY GUN AND GOOD
PERFORMANCE AT NEXT USE.
DURING CLEANING, ALWAYS WEAR PROTECTIVE CLOTHING SUCH AS GLASSES, MASK OR GLOVES TO AVOID
SERIOUS INJURY CAUSED BY PAINT OR SOLVENT WHICH COULD COME INTO CONTACT WITH EYES OR BE
INHALED.
WARNING
AIR PRESSURE : 0 BAR
FLUID PRESSURE: MINIMIZED
BEFORE DISASSEMBLING AND MAINTENANCE OPERATIONS, BE SURE ALWAYS TO STOP PUMP, REDUCE AIR AND
CAUTION
FLUID PRESSURE DOWN TO "0 bar" AND APPLY SAFETY LOCK TO MULTI SPRAY GUN.
8
Multi Spray Manual Gun
3
CLEANING NOZZLE
Multi Spray Manual Gun
MSGS-200 EVO |
12.1 DISASSEMBLING OF FLUID NOZZLE, NEEDLE & NEEDLE PACKING
1
2
5
6
12.2 REASSEMBLING OF NEEDLE PACKING, NEEDLE & FLUID NOZZLE
1
2
4
5
3
4
7
3
A
B
6
7
EN
9
