PARTS
1. Control panel
2. Air outlet
Wheels
3.
4. Handle
5. Permanent drainage
6. Air outlet
7. Plug storage
8. Cord storage
9. Bottom drain
10. Air inlet + air filters
11. Drain hose
12. Air outlet hose
Window connection kit
13.
Window adaptor
·
Connecting hose/window adapter
·
Window seal
·
· Adapter plug
· L-iron with screws
14. Wall connection kit
Connecting hose/ Wall adaptor
·
Wall adaptor
·
· Screws and plugs
15. Cable storage accessory
16. Remote control including batteries, suspension holder, and screws
Hose/appliance connector
17.
11
13
14
