Connect Controller has an IP44 external aerial for receiving the signal from a remote control or a WiFi signal for it to work from the
Fluidra Pool app. It can be installed anywhere except for corrosive environments, metal boxes and close to metal piping or wiring that
block the signal. Make sure to install the aerial in a location with a good WiFi signal. The cable, which does not have polarity, must be
connected to terminals no. 15 and no. 16 on the modulator.
3.2 WIRING DIAGRAM (See page 46, fig. 1 fig 2)
4. OPERATION
Turn on the power for the Connect Controller and the projectors:
• Control from the Fluidra Pool app.
During the app installation process, it is recommended that you be close to the aerial with your smartphone.
Download and install the Fluidra Pool app on your smartphone. During the app installation process you will be asked
to scan the QR code that can be found on the aerial or on a label inside the Connect Controller box.
Turn on the power for the Connect Controller and the projectors and follow the steps as instructed in the Fluidra
Pool App.
Fluidra Pool app has been adapted for compatibility with both Android and iOS operating systems.
• Control from remote control (codes 76291 and 76292).
In addition to the Fluidra Pool App, the Connect Controller can also be operated using a remote controller. During the pairing process,
ensure that you are within 15 meters of the aerial and have a clear line of sight to the pool's projectors.
Pairing process
1. Connect the Connect Controller and the projectors to the 12 V AC network (you will have 5 minutes to complete the process, or you
will need to start again). NOTE: If more than one projector is installed, the pairing of all projectors must be carried out simultaneous-
ly.
2. Press the ON/OFF button on the remote control for at least 10 seconds until the LEDs turn a fixed blue.
3. After 5 seconds, the remote control's LEDs will switch off, and the projector's lights will flash white.
4. The pairing process is complete when the projector's white lights remain completely fixed for 10 seconds before switching off.
LED flashing red: Connect projectors successfully detected and communicating.
LED flashing green: Essential projectors successfully detected and communicating.
5. SAFETY WARNINGS
• Installation, assembly and maintenance work must be carried out by a qualified service engineer.
• The service engineer must fulfill all health and safety regulations in force during the assembly, installation and start-up of the product.
• All contact with electric current must be avoided. Whenever the spotlight is handled, it must be switched off from the mains.
• The service engineer and the user must abide by all regulations in force on hazard prevention.
• Do not handle if you are standing in water.
• Any modifications to the product will require the manufacturer's prior consent.
• The manufacturer accepts no liability for any damage or malfunction caused by the use of unauthorized spare parts.
• The installation must comply with standard IEC/HD 60364-7-702: Requirements for special installations or locations. Swimming pools
and fountains.
• If you change your WiFi operator or the WiFi device is changed, the system must be reconnected.
• If the WiFi signal between Connect Controller and your smartphone is lost, the projectors will not respond to commands.
3
Download the
