ENGLISH
NOTE: This instruction manual contains essential information about the safety measures to be adopted when the product is being
installed, operated for the first time or maintenance work carried out on it. Therefore, both the service engineer and the user must
read the instructions carefully before beginning installation and start-up. Keep this manual for future reference about how this product
works. This manual may be read on and downloaded from the website at www.astralpool.com.
Please follow the instructions below to achieve the best results from the LumiPlus Connect Controller.
1. CHECK THE CONTENT OF THE PACKAGING:
- LumiPlus Connect Controller
2. GENERAL SPECIFICATIONS
Connect Controller is a control module for the LumiPlus Connect range of luminaires. This module must be controlled from the Fluidra
Pool app or by using one of the remote controls from AstralPool's LumiPlus Connect family (codes 76291 and 76292).
Connect Controller must be installed indoors (IP20). It has an aerial that can go outdoors (IP44), in which case it must be placed where
there is a good WiFi signal so that it is able to connect to the Fluidra Pool app. The functions will be different depending on the type
of luminaire that is connected (white, tunable white, RGB or RGBW) and how Connect Controller is controlled (smartphone or remote
control).
NOTE: Connect Controller is also compatible with LumiPlus Essential RGB or RGB RC1100 range; LumiPlus RGB V1 or V2 projectors.
3. INSTALLATION
• Install Connect Controller so that it is protected from corrosive environments.
The modulating equipment must be installed on a DIN rail inside an electrical panel with a cover. This cover must have a key or lock so
that the equipment is not accessible after installation.
For the electrical connection, it is necessary to incorporate a disconnect switch in accordance with installation reg-
ulations, ensuring omnipolar disconnection, directly connected to the supply terminals. The disconnection device
must be connected as close as possible to the input supply.
Installation with LumiPlus Connect projectors:
Connect it to the secondary winding of the 12 V AC (50/60 Hz) transformer using terminals no. 2 and no. 3.
The LumiPlus Connect projectors are connected directly to the transformer (see Fig. 3, page 47).
Connect Controller does not have a power limit. The top power output of the LumiPlus Connect projectors to be
connected will be dictated by the transformer's maximum capacity. It is recommended that only one Connect Con-
troller be installed for each transformer. In the case of dual output transformers, the outlets must be connected to it so that it works
properly or a Connect modulator installed for each outlet.
Installation with LumiPlus Essential projectors or LumiPlus RGB V1 or V2 projectors:
Connect it to the secondary winding of the 12 V AC (50/60 Hz) transformer using terminals no. 2 and no. 3. projectors should be con-
nected to terminals no. 4 and no. 5 (See Fig. 4, page 47).
In this operating mode, Connect Controller allows a top load of 150 VA.
3.1. AERIAL
Connect Controller can either be controlled from the Fluidra Pool app or remote controls (codes 76291 and 76292, depending on the
model of projector).
- Aerial
2
- Instruction manual
How to
install
