Aidoo Pro Fancoil
accessories
AIRQ BOX
Devices included in the solution:
•
AZAI6WSPFAN - Aidoo Pro Fancoil
•
AZX6AIQBOXM - AirQ Box Air Purification
Connection
Connect the INT port of the Aidoo Pro Fancoil to the AZ1 Port of the AirQ Box.
AZX6AIQBOXM
AIRQ SENSOR
Devices included in the solution:
•
AZAI6WSPFAN - Aidoo Pro Fancoil
•
AZX6AIQSNSx - AirQ Indoor Air Quality Sensor
Connection
Connect the INT port of the Aidoo Pro Fancoil to the RS485 port of the AirQ Box.
AZAI6WSPFAN
INT
AZX6AIQSNSB
RS485
AZAI6WSPFAN
INT
