3. Usageand Application Scope
EX-VIEW 03.5606 is a Handheld Rechargeable Work Light and portable explostion-proof
(abbre.Explosion-proof light in the following instruction). suitable for using in explosive area of Zone 2. Zone 22,
GasgroupIIA/IIB/I C.dustgroup A/IIIB/II C andTemperatureGroupTl WT5/TIOOC. It is suitablefor usingin
temporary local auxiliary lighting and local main lighting for the industries of petroleum produce. smelting. chemical.
pharmaceutical, brewing, military reserve, etc.
4. INSTRUCTION
• Before use.pleasecheckwhetherthe packingis ingood condition.if there is anyvisible damageof the light and
adapter. Before using the light. please check if there is any visible damage of the structure or "abnormal sound"
inside.Pleaseopenthe light to checkif the damage will influencethe explosion-proofperformanceandmake
appropriate treatment.
• Please check if the explosion-proof light nameplate parameters listed are conformed to the actual conditions of
use.
• The explosion-proof light is composed of head light and adaptor.
• The explosion-proof light can realize two lighting mode - spot light and flood light. The switch sequence is spot
light flood light. It has infrared sensor function as well
sensorwill beon. andusercanpressthe on/off switch to chooseneededmode(spot light or flood light).then
waving the hand twice against the sensor can switch the light on and off.
• Please charge the light under the circumstance between
charging. First. please make sure the effective connection between the light and adapter. Second. plug the
adaptor to AC power supply. The conversed operation is prohibited.
• The explosion-proof light has charging indication function: the charging indicator will be on "red" during charging.
and the charging indicator turns to be "green" when it is fully charged.
The following operations are prohibited in any possible dangerous area:
Open the light when it is working or turning off the load.
Regular or occasional maintenance and repair.
Operating under explosive atmosphere. fasten protection cap of charger. do not open the protection cap under
explosive atmosphere.
• The persons who use the light at site should know about the performance of explosion-proof light. Turn off the
light in time and evacuate the dangerous area when find any abnormal phenomenon. Unqualified repair person is
not allowed to repair the explosion-proof lights.
5. MAINTENANCE
• When installation, use and maintenance, observe following standards IEC60079 10, IEC6007g 14, IEC6007g 17
and IEC 60079-19
• The service man must have on the-job training to knavethe specification and operating performance of
explosion-proof light. They must have professional knowledge and should familiar with the structure of explosion
proof light,
• Clean the dust and dirt on the shell of the explosion-proof light regularly to improve the luminous efficacy and
heat dispersion performance. A wet cloth can be used for cleaning.
• Check whether the transparent parts have been impacted by foreign body regularly. Check whether the
fasteners and inner components are loose, soldering off or corroded. If yes, do not use it until maintained.
If use the light in damp environment. please regularly check and change the sealing components to ensure the
protective performance of the shell.
• When disassemble the light, must comply with the warning requirements to operate in nan-dangerous area.
• After open the shell, should check whether the sealing components become hard or adhesive; whether the
insulating layer of the wire become green or carbonized; whether the insulating parts
and electrical components become deformed or have scorch. If these problems are found, must repair the light
immediately,
• The model. specification, dimension and performance of the parts for maintaining should keep the same as the
original ones,
• Check whether the sealing ring is at the original location by achieve the sealing function when close the shell.
• Do not disassemble the sealing parts of the light often. Otherwise the explosive proof function will be affected.
when the sensor function is switched on. the indicator of
Cto •450 C. Please pay attention to the orders when
head light
