3.3.6. Image Filter
3.3.6.1: Clean noise: This is a filter which is clean noise in the screen.
3.6.6.2: Adjustment: To control of color value that is input video.
3.3.7. Video Type: Select the type of output file.
3.3.8. Quality: Adjust the quality of the output file. (Best/Good/Normal/Average)
3.3.9. Split Size: Split size takes the guess work out by automatically splitting the file
size of capture video according to the format and disc capacity you will be
using to burn your movie. The output files are partitioned according to the
capacity of the disk to be burned (CD/DVD).
3.3.10. Recording duration time: Set the recording duration time you want. This is
very handy when you know the duration of the movie you are capturing. You
don't have to monitor the capture process, just set the recording duration and
will HT Video to DVD will stop once this time expires. It is always good idea to
set record duration time. If not set, recording will continue up to the maximum
recording time.
3.3.11. Commercial Cutting: This function is cutting a scene which not be want to
included at the recording file like to a commercial scene, that is only work at
recording status. At the first, start recording and click
the CM and click
combolist. Do again when you want to cut like this, and after stop recording it
should be changed to Edit and add the list of cuttime date in the storybook. If
you want to detail cut of the cut clip, you dobule click the clip that you can see
the time range at the play panel and control a seekbar and click
applied, At the last, click
3.3.12. Output Folder: Specify the location where the capture video will be saved.
3.3.13. Recording and Burning: If checked, starts burning process right after
recording for the designated time. This is ideal when you are copying your
home videotapes into DVD disc. Makes the whole process automatic.
3.3.14. Start button: After all the configurations are set you can simply click on this
button to start the capture process.
3.3.15. Stop button: Click on this button when you are not using the record time
duration. Also when you want to stop the record process. Everything recorded
prior to pressing this button will be saved into a file.
3.3.16. Current Status: Displays the status of the recording depending on your
recording durations time, or the maximum record time.
Chapter 3. Operation
after end CM and then the cuttime data be add to a
it should be output a file.
7
when come out
then be
