Assembly or replacement of the saw blade
Disconnect the mains plug before any installation or conversion work on the
device.
To be injured, wear gloves when changing the saw blade! Never change or
dismantle the saw blade without protective gloves!
• Remove the cutting Saw blade guard. See page 14 ff.
• Screw the two countersunk head screws (31) out of the table insert (32) on the left
and right. See Fig. 7.
• Remove the table insert.
• Loosen the screws (33) on the split wedge slightly. See Fig. 8, p.17..
• Remove the split wedge by carefully pulling the split wedge in the body direction.
• Unscrew the mounting screws (35) of the running guard on the left and right of the
running guard (34). See Fig.9, p.17.
• Remove the running guard.
16
31
32
Fig. 7
V. 1.0
EN
