Legend Figure 1 and 2
1. Saw Table
2. Transverse stop (complete)
3. Groove in saw table
4. Saw blade guard (complete
5. Saw blade
6. Parallel stop (complete)
7. Angle scale
8. Locking handle for saw blade angle (front)
9. Sliding Stick
10. Foot
1 1. On/off switch
12. Scale (Cutting Width)
13. Locking handle for saw blade angle (rear)
14. Suction Adapter
15. Locking screw for parallel stop
16. Splitting wedge
17. Mains plug on holder
