8.2 ESQUEMA PARÁMETROS
Key 0
UF1 bLit
Key 1
Key 0
Key 1
Key 2
Key 3
Key 4
Key 5
Key 6
UF2 rs232 Key 7
Key 8
Key 9
Keys 1+0
Keys 1+1
Keys 1+2
Keys 1+3
Keys 1+4
UF3 bAUd Keys 0 to 4
UF4 ModE Keys 0 to 3
UF5 AtArE Keys 0 to 1
UF6 nUMbEr Keys 0 to 1
UF7 PAritY Keys 0 to 2
UF8 StoP Keys 0 to 1
UF9 CPriCE Keys 0 to 1
To go from a "uf" menu to another, the keys of
For to save the settings the user have to press
5 4 3 2 1
9 8 7 6
To turn off the screen backlight.
To select automatic screen backlight.
nonE - Without selecting any protocol.
TPU_A - to select the TPV0 type A protocol.
TPU_b - to select the TPV0 type B protocol.
TPU_2A - to select the TPV-2A protocol.
TPU_2B – to select the TPV-2B protocol.
TPU_4 – to select the TPV-4 (Berkel) protocol.
TPU_7 – to select the TPV-7 protocol (Samsung).
TEdC1 – to select the TED-C1 (CAS) protocol.
tiSA_A – to select the TISA-A protocol.
tiSA_S – to select the TISA-S protocol.
toLEdo – to select the Toledo protocol.
nCiECr – to select the NCI-ECR protocol.
nCiGEn – to select the NCI-General protocol.
AnkEr - to select Anker protocol.
EPSA - to select Epelsa protocol.
With the 0 to 4 keys we will select the Baud: 1200, 2400, 4800, 9600 and 19200
respectively.
With the keys 0 to 3 we will select the sending mode of the TPV0 protocol: TrAn0 (At
the request of the PC), TrAn1C (Continuous Frame-A Mode), TrAn1M (Continuous
Frame-B Mode) and TrAn2 (Manual Mode) respectively.
The rest of the protocols always work upon request as detailed in the corresponding
document.
With the keys from 0 to 1, we deactivate or activate respectively the auto-clear tare
function.
With the keys from 0 to 1, we will select the number of bits in the communication data:
7 and 8 respectively.
With the keys from 0 to 2, we will select the parity in the communication data: nonE
(none), EvEn (even), and odd (odd) respectively.
With the keys from 0 to 1, we will select the number of stop bits in the communication
data: 1 and 2 respectively.
With the keys from 0 to 1, we deactivate or activate respectively the auto-clear price
function when passing through gross zero.
and towards the left or right respectively.
.
Pin 2 Tx
Pin 3 Rx
Pin 5 GND
