Atlas Copco Control Thin Legic Sicherheitshinweise Seite 3

Assembly Control Thin Legic
Technical Data
Industrial PC Data
Input Voltage
Power (W)
Input Current (A)
Relative Humidity (min.)
Relative Humidity (max.) 95
Operating Conditions
Operating Temperature 0°C (min)
32°F (min)
Relative Humidity % 5 (min.)
Maximum Radio Output Power
Radio Technology Frequency Range
RFID 13.5 MHz
125 kHz
Declarations
Liability
Many events in the operating environment may affect the
tightening process and shall require a validation of results. In
compliance with applicable standards and/or regulations, we
hereby require you to check the installed torque and rotational
direction after any event that can influence the tightening re-
sult. Examples of such events include but are not limited to:
• initial installation of the tooling system
• change of part batch, bolt, screw batch, tool, software,
configuration or environment
• change of air- or electrical connections
• change in line ergonomics, process, quality procedures or
practices
• changing of operator
• any other change that influences the result of the tighten-
ing process
The check should:
• Ensure that the joint conditions have not changed due to
events of influence.
• Be done after initial installation, maintenance or repair of
the equipment.
• Occur at least once per shift or at another suitable fre-
quency.
EU DECLARATION OF CONFORMITY
We, Atlas Copco Industrial Technique AB, SE-105 23
STOCKHOLM SWEDEN, declare under our sole responsi-
bility that the product (with name, type and serial number, see
Assembly Control Thin Legic
100-240 VAC
50
0.5
5
40°C (max)
104°F (max)
95 (max.)
Maximum Trans-
mit Power EIRP
5 dBm
12 dBm
© Atlas Copco Industrial Technique AB - 9846 1192 00
front page) is in conformity with the following Directive(s):
2011/65/EU (RoHS), 2014/53/EU (RED), 2015/863/EU
(RoHS amendment)
Harmonized standards applied:
EN 300330 V2.1.1 EN 301 489-1 V2.2.3 EN 301 489-3
V2.3.2, EN IEC 61000-6-2:2019 EN IEC 61000-6-3:2021
EN 62368:2014/A11:2017 EN IEC 63000:2018
Authorities can request relevant technical information from:
Product Compliance Manager, Atlas Copco Industrial Tech-
nique AB, SE-105 23 Stockholm Sweden
Stockholm, 1 November 2022
Lars Eklöf, Managing Director
Signature of issuer
WEEE
Information concerning Waste of Electrical and Electronic
Equipment (WEEE):
This product and its information, meets the requirements of
the WEEE directive/regulations (2012/19/EU), and must be
handled in compliance with the directive/regulations.
The product is marked with the following symbol:
Products marked with a crossed-out wheeled bin symbol and
a single black bar underneath, contain parts that must be han-
dled in compliance with the WEEE directive/regulations. The
entire product, or the WEEE parts, can be sent to your "Cus-
tomer Center" for handling.
Conformity to North American Standards
Complies to:
UL 62368-1, 3rd ed.
CSA C22.2 No.62368-1:19, 3rd ed.
UK DECLARATION OF CONFORMITY
We, Atlas Copco Industrial Technique AB,
SE-105 23 STOCKHOLM SWEDEN, declare
under our sole responsibility that the product
(with name, type and serial number, see front
page) is in conformity with the following UK
Regulation(s):
S.I. 2012/3032, S.I. 2016/1101, S.I. 2017/1206
Safety Information
3
