LASER DISTANCE METER
EN
Press
* If press and hold
Addition/Subtraction
Press
Press
Press or
Press
12 12
If sound signal is on, when approaching the stake-
out point the product emits sound signal. When
reaching the stake-out point symbol
on the display and sound signal tonality is changed.
– distance between the object and stake-out point
of last measured distance. This value will increase
after each next measurement by the value of last
taken measurement.
– value of distance A
– value of distance В
– current distance to the next stake-out point.
Mark point А and go on moving the product
along stake-out line until you reach point B. If it
is necessary to transfer several equal distances,
repeat the last operation required number of
times.
Stop the measurement
or the speed is increased.
Switch on the laser beam. Aim the product at the
object of measurement.
First measurement.
Measuring result appears in the main line.
Activate addition
Switch on the laser beam. First measuring result
moves to the line 2 on the display.
XP3 PRO CONDTROL
or subtraction .
User manual
appears
