11

Maintenance and calibration

11.1 Sensor replace-
ment
2
Fig. 21: Protective cap (1) and probe tip
with inserted sensor (2)
Fig. 22: Sensor and sensor holder
The sensor must be replaced once a year.
The sensor can be replaced very easily as follows:
• Unscrew the protective cap (1) from the probe
tip.
Pull the sensor (2) out of the holder.
•
1
Insert the new sensor into the holder.
•
Make sure that the black bar of the sensor is
•
guided into the small recess on the sensor
holder.
The sensor can only be positioned the right way
round. If you insert it the wrong way round, it can-
not be pressed down.
• Screw the protective cap back onto the sensor
holder.
ATTENTION!
To activate the newly installed sensor, switch the
device on for at least one hour before the leak de-
tection. To do this, deactivate the automatic
switch-off function (press and hold the power but-
ton and M button simultaneously).
Maintenance and calibration
NOTE!
EN
37
