For the installation, you need one of the following lamps, depending upon device version:
OMNILUX OQI-TS 150W R7s 6000h
OMNILUX OQI-T 250W E40 6000h
OMNILUX OQI-T 400W E40 6000h
The lamp must only be changed when wearing appropriate protective clothing (protection glasses, protection
gloves, helmet with sight, leather apron).
The lamp life given by the manufacturer must never be exceeded. This is why you need to take notes on the
operational time of the lamp and replace the lamp in time.
Keep exchanged lamp in a protective container and remove accordingly.
Before replacing the lamp, unplug mains lead and let the lamp cool down (approx. 10 minutes).
During the installation do not touch the glass-bulbs bare-handed! Please follow the lamp manufacturer's
notes!
Do not install lamps with a higher wattage! Lamps with a higher wattage generate temperatures the device
was not designed for. Damages caused by non-observance are not subject to warranty.
Procedure:
Step 1: Remove the clips on the housing cover
with an appropriate tool (See picture).
Step 2: Open the cover.
Step 3: If replacing the lamp, remove the old
lamp from the lamp holder.
Step 4: Insert the lamp into the lamp holder.
Step 5: Replace the cover and affix the clips.
91013125
91013190
91013195
CAUTION!
The lamp has to be replaced when it is damaged
or deformed due to the heat!
