IMPORTANT!
Surface temperature differs from the internal temperature of human body. For measuring the body temperature,
always use „BODY" mode. Make sure you select "SURFACE TEMP" mode to read the external area only.
3.In turned on state, press the
4.In turned on state, press the button "MEM" (Memory), which will show the last measured temperature and will show last 32
measurements. If again, in turned on state, you press the button "MEM" and hold it for 5 seconds, all data will be deleted.
After this press again „MEM" button and the display will show „CLr".
5.In turned on state, press the buttons "MODE" and "°C/°F" at the same time for 3 seconds. The display will show: "F4", and
then press "MEM" button to enter into F5 (ON or OFF functions). Press MODE to display "ON" and the buzzer is active.
Press "°C/°F" to display "OFF", and the buzzer will not be active. Press "MEM" to confirm setting.
6.Device calibration though menu F4:
that the mercury thermometer is more accurate but not comfortable for using. You can use calibration function to tune Easy
Check and to receive the value, same as this on the mercury thermometer. Furthermore, when you use Easy Check for
people with different skin color (for example from yellow, white or black race), you can also use calibration.
➢Calibration instructions
a.In turned on state, press the buttons "MODE" and "°C/°F" at the same time for 3 seconds.
b.The display will show: "F4".
c.Press ""MODE", to increase with 0.1°C, press "°C/°F", to decrease with 0.1°C.
d.Press "MEM" button twice, to keep the settings.
e.In case of seasonal or ecological changes, a check and device regulation must be done.
Items
Battery
Temperature sensor
Measuring distance
Measurement range
Measuring accuracy
Clinical repeatability
Display resolution
Measurement Time
Memory
Operation Environment
Storage and transportation condition
Weight
Product Size
Expected Service Life
Automatic power-off
button, °C/°F", to switch between Celsius and Fahrenheit.
When there is difference between Easy Check and mercury thermometer, you believe
VII. TECHNICAL CHARACTERISTICS
Specifications
DC 3V (2 pcs AAA batteries)
Infrared Sensor
3cm - 5cm(1.2in - 2in)
Body temperature mode:
32.0°C ~ 43.0°C (89.6°F ~ 109.4°F)
Under body mode, there is three color backlits:
Green color backlit: ≤ 37.3°C (99.1°F), means normal temperature.
Orange color backlit: 37.4°C - 37.9°C (99.3°F - 100.2°F), means may be low fever.
Red color backlit: ≥ 38°C (100.4°F), means may be high fever.
Surface temperature mode:
0°C ~ 60°C (32°F ~ 140°F)
Room temperature mode:
0°C ~ 40°C (32°F ~ 104°F)
Body temperature mode:
32.0°C ~ 34.9°C (89.6°F ~ 94.8°F) : ±0.3°C (±0.6°F)
35.0°C ~ 42.0°C (95°F ~ 107.6°F) : ±0.2°C (±0.4°F)
42.1°C ~ 43.0°C (107.8°F ~ 109.4°F) : ±0.3°C (±0.6°F)
≤ 0.2°C (0.4°F)
0.1°C (0.1°F)
1 second
32 sets
Ambient temperature: 10°C ~ 40°C (50°F ~ 104°F)
Relative humidity: ≤85%RH
Atmospheric Pressure: 700 hPa to 1060 hPa
Ambient temperature: -20℃ ~ 55℃ (-4℉ ~ 131℉)
Relative humidity: ≤ 95%RH
Atmospheric Pressure: 700 hPa to 1060 hPa
Approx. 67g (Battery excluded)
Approx. 130 x 45 x 55 mm (L x W x H)
5 years
≤ 30 secs
