Frico SWH Bedienungsanleitung Seite 3

Fan heater SWH
1. Fan heater SWH
2. Mounting brackets SWB
3. Basic filter SWFTN
4. Filter section, deep-pleated bagfilter EU3 SWF
5. Return air intake SWD
6. Extra air director, adjustable louvres SWLR
1. Fläktluftvärmare SWH
2. Monteringskonsoler SWB
3. Trådnätsfilter SWFTN
4. Filterskåp, djupveckad filterkassett EU3 SWF
5. Distansdel för filterskåp SWD
6. Extra luftriktare, ställbara lameller SWLR
Dimensions
Inlet
Outlet
ø
Type
SWH02
SWH12
SWH22
SWH32/33
Minimum distance
min 850 mm
A
B
A B C
[mm] [mm] [mm]
525 515 320
600 535 340
725 680 370
850 820 450
SWH
6
F
G
H
E
C
D
E F G
[mm] [mm] [mm]
95 70 70
95 70 70
100 70 70
100 70 70
Type
SWH02
SWH12
SWH22
SWH32/33
3
2
4
1
I
J
H I J
[mm] [mm] [mm]
390 405 260
465 470 260
585 580 400
710 700 530
D
[mm]
40
70
67
155
5
K
K Ø
[mm] [mm]
70 22
70 22
75 28
75 28
3
