Fan heater SWH (IP44)
Item Type Heat
number output*
[kW]
SWH02
4380 6,8/11
4381 SWH12 8,7/17
4382 SWH22 19/29
4383 SWH32 29/44
4384 SWH33 32/53
* ) Applicable at water temperature 80/60 °C, air temperature, in +15 °C.
1
*2) Applies to fan position 1 / 4.
* ) Sound power (L ) measurements according to ISO 27327-2: 2014, Installation type E.
3
WA
* ) Sound pressure (L
4
pA
absorption area: 200 m².
* ) ∆t = temperature rise of passing air.
5
* ) Water volume inside water coil.
6
SWH is delivered pre-programmed in Automatic control, fan position 4. For optimum performance of heat
output and sound level, fan speeds up to step 4 are recommended. Fan position 5 is available in Manual
control.
Approved for 220V/1ph/60Hz. Product performance for 220V/1ph/60Hz will differ from stated data.
Air throw
Type Air throw
[m]
SWH02 7
SWH12
11
SWH22 19
SWH32
25
SWH33 23
The air throw data above is valid at fan position 4 and room temperature +18 °C. The air throw is defined as
the distance in a straight angle from the fan heater to the point where the average air speed has dropped to
0,5 m/s.
Air Air
flow* flow*
1,2 2
[m³/h] [m³/s]
450/1000 0,13/0,28
760/2020 0,21/0,56
1770/3370 0,49/0,94
2670/5200 0,74/1,44
2250/4450 0,62/1,23
). Conditions: Distance to the unit 5 metres. Directional factor: 2. Equivalent
Air throw with
extra air director
[m]
-
17
25
33
29
SWH
Sound Sound
power* pressure*
2 3
[dB(A)] [dB(A)]
56 19/40
64 26/48
70 40/55
67 39/51
66 38/50
Extra air director
Water Amperage
∆t*
1,2,5
volume*
2,4 6
[°C] [l] [A]
38/30 1,3 0,34
34/24 1,5 0,7
31/25 2,7 1,2
31/25 3,8 1,7
41/35 5,2 1,7
SWH
Voltage: 230V~
Weight
[kg]
20
24
34
55
59
