05
For the electrical connection fuselage / wing,
the 6-pin Mulltiplex connectors are used,
which can optionally be left loose or perma-
nently installed.
07
The receiver should be attached laterally on
the servo board.
The fixed installation requires a bit more ef-
fort at the beginning, but facilitates the as-
sembly of the FOX later on the airfield enor-
mously.
Now mount the main and tail wheel with Al-
len screws, nuts and spacers and pay atten-
tion to ease of movement.
ASSEMBLY THE WINGS
The wing is already finished with servos and cables and
therefore requires only little work.
For the electrical connection fuselage / wing, the 6-pin
Mulltiplex connectors are also used here, which can
either be left loose or permanently installed (see fuse-
lage). The fixed installation requires a bit more effort at
the beginning, but facilitates the assembly of the FOX
later on the airfield enormously.
ENGLISH
06
08
13
