Installation of door handle (optional)
As shown in the figure, align the two round holes inside the handle base with the
1.
reserved holes on the door , and use the self-contained Phillips screwdriver to fasten
the two hexagon screws until the handle base does not shake.
Align the handle with the upper and lower guide slots on the handle base , and push
2.
the handle horizontally from left to right as shown in the figure until it reaches the
end.
Align the countersunk screw with the reserved hole on the lower side of the handle
3.
EN
and secure it tightly.
( The picture above is only for reference. The actual configuration will depend on the physical
product or statement by the distributor )
Leveling feet
To avoid vibration, the unit must be leveled.
If required, adjust the leveling screws to compensate for the uneven floor.
The front should be slightly higher than the rear to aid in door closing.
Leveling screws can be turned easily by tipping the cabinet slightly.
Turn the leveling screws counterclockwise
lower it.
ATTENTION
To remove the handle, you need to remove the screw
first, and then slightly shake the handle to push it out in
the opposite direction (from right to left). Be careful not
to push it hard horizontally to avoid hitting your fingers.
to raise the unit, clockwise
06
to
