Proline Promag H 300 EtherNet/IP
Endress+Hauser
9.4.2 Ein- und Ausgangsgruppen
Mögliche Konfigurationen
Konfiguration 1: Exclusive Owner Multicast
Input Assembly Fix
Input Assembly Configurable
Output Assembly Fix
Input Assembly Fix
Konfiguration 2: Input Only Multicast
Input Assembly Fix
Input Assembly Configurable
Output Assembly Fix
Input Assembly Fix
Konfiguration 3: Exclusive Owner Multicast
Input Assembly Configurable
Input Assembly Configurable
Output Assembly Fix
Input Assembly Fix
Konfiguration 4: Input Only Multicast
Input Assembly Configurable
Input Assembly Configurable
Output Assembly Fix
Input Assembly Fix
Konfiguration 5: Exclusive Owner Multicast
Input Assembly Fix
Input Assembly Configurable
Output Assembly Fix
Input Assembly Fix
Konfiguration 6: Input Only Multicast
Input Assembly Fix
Input Assembly Configurable
Output Assembly Fix
Input Assembly Fix
Instanz
Konfiguration 0 x 64
O → T Konfiguration 0 x 66
T → O Konfiguration 0 x 64
Instanz
Konfiguration 0 x 68
O → T Konfiguration 0 x C7
T → O Konfiguration 0 x 64
Instanz
Konfiguration 0 x 68
O → T Konfiguration 0 x 66
T → O Konfiguration 0 x 65
Instanz
Konfiguration 0 x 68
O → T Konfiguration 0 x C7
T → O Konfiguration 0 x 64
Instanz
Konfiguration 0 x 69
O → T Konfiguration 0 x 66
T → O Konfiguration 0 x 64
Instanz
Konfiguration 0 x 69
O → T Konfiguration 0 x C7
T → O Konfiguration 0 x 65
Systemintegration
Größe (Byte) min. RPI (ms)
398 –
64 5
44 5
Größe (Byte) min. RPI (ms)
398 –
– –
44 5
Größe (Byte) min. RPI (ms)
398 –
64 5
88 5
Größe (Byte) min. RPI (ms)
398 –
– –
88 5
Größe (Byte) min. RPI (ms)
– –
64 5
44 5
Größe (Byte) min. RPI (ms)
– –
– –
44 5
