Roller Smart-Cut Betriebsanleitung Seite 8

eng
● Check the power cable of the power tool and, if applicable, extension leads
regularly for damage. Have these renewed by qualified experts or an authorised
ROLLER customer service workshop in case of damage.
● Only use approved and appropriately marked extension leads with a suffi-
cient cable cross-section. Use extension leads up to a length of 10 m with
cable cross-section 1.5 mm², from 10 – 30 m with cable cross-section 2.5 mm².
Safety Notes for Batteries, Rapid Chargers
WARNING WARNING
Read all the safety notes, instructions, illustrations and technical data which
come with this power tool. Failure to heed the instructions can result in electric
shock, fire and/or severe injuries.
Keep all safety notes and instructions for the future.
See also www.albert-roller.de → Downloads → Instruction Manuals
Safety Data Sheets
WARNING WARNING
Read the safety data sheets. Failure to heed the instructions can result in electric
shock, fire and/or severe injuries.
Keep all safety notes and instructions for the future.
See www.albert-roller.de → Downloads → Safety Data Sheets → Batteries.
Explanation of symbols
WARNING WARNING
Danger with a medium degree of risk which could result in death
or severe injury (irreversible) if not heeded.
CAUTION CAUTION
Danger with a low degree of risk which could result in minor injury
(reversible) if not heeded.
NOTICE NOTICE
Material damage, no safety note! No danger of injury.
Read the operating instructions before use
ROLLER'S Smart-Cut complies with protection class I
ROLLER'S Smart-Cut 11 V and rapid charger comply
with protection class Il
Not suitable for using outdoors
Environmentally friendly disposal
CE conformity mark
1. Technical Data
Use for the intended purpose
WARNING WARNING
ROLLER'S Smart-Cut and ROLLER'S Smart-Cut 11 V are intended for the purpose
of cutting pipes.
All other uses are not for the intended purpose and are prohibited.
Guidelines for use of ROLLER'S cordless tools, batteries, rapid chargers, power
supply units.
See www.albert-roller.de → Downloads → Instruction Manuals → CROPPING,
CUTTING AND DEBURRING TECHNOLOGY: OTHER DOCUMENTS
1.1. Scope of Supply
ROLLER'S
Smart-Cut: Electric pipe cutting machine (without cutting wheel),
single open-ended wrench size 8, operating instructions,
carrying case.
ROLLER'S
Smart-Cut 11 V: Cordless pipe cutting machine (without cutting wheel),
Li-Ion battery, rapid charger, single open-ended wrench
size 8, operating instructions, carrying case.
1.2. Article numbers
ROLLER'S Smart-Cut
ROLLER'S Smart-Cut 11 V
ROLLER High-Power-Battery Li-Ion 10.8 V, 2.5 Ah
Rapid-charger 220 – 240 V, 65 W
ROLLER cutting wheel Cu-INOX
ROLLER cutting wheel V
ROLLER'S Assistent 3B
ROLLER'S Assistent WB
8
ROLLER'S Werkmeister
ROLLER'S Werkmeister E
Carrying case
System case L-Boxx with inlay
1.3. Application Area
ROLLER'S Smart-Cut, ROLLER'S Smart-Cut 11 V:
Pipes of pressfitting systems made of
● stainless steel, C-steel (not jacketed)
● semi-hard and hard copper
● composite pipes
Operating temperature range
ROLLER'S Smart-Cut,
ROLLER'S Smart-Cut 11 V
Battery
Rapid charger
1.4. Speed
ROLLER'S Smart-Cut, ROLLER'S Smart-Cut 11 V:
Idle speed of cutting wheel
1.5. Electrical Data
ROLLER'S Smart-Cut:
230 V~; 50 – 60 Hz; 130 W
Fuse (mains) 10 A (B), cut-out operation S3 20% AB 2/10 min,
radio interference suppressed, protection class I, PE conductor as of
machine no. 3650
ROLLER'S Smart-Cut 11 V:
10.8 V – ---; 2.5 Ah
Rapid-charger
Input
Output 10.8 – 18 V – ---
Input
Output 10.8 – 18 V – ---
1.6. Dimensions
ROLLER'S Smart-Cut:
L × W × H:
ROLLER'S Smart-Cut 11 V:
L × W × H:
1.7. Weights
ROLLER'S Smart-Cut
ROLLER'S Smart-Cut 11 V drive machine without battery
ROLLER'S battery Li-Ion
1.8. Noise Data
Workplace-related emission value
L
wA
1.9. Vibrations
Weighted effective value of the acceleration
The indicated weighted effective value of acceleration has been measured
against standard test procedures and can be used by way of comparison with
another device. The indicated weighted effective value of acceleration can also
be used as a preliminary evaluation of the exposure.
CAUTION CAUTION
The indicated weighted effective value of acceleration can differ during operation
from the indicated value, dependent on the manner in which the device is used.
Dependent upon the actual conditions of use (periodic duty) it may be necessary
to establish safety precautions for the protection of the operator.
2. Start-up
2.1. Electrical Connection
WARNING WARNING
Caution: Mains voltage present! Before connecting the electric pipe cutting
machine or the rapid charger, check whether the voltage given on the rating
plate corresponds to the mains voltage. Only use sockets/extension leads with
a functioning protected earth contact for ROLLER'S Smart-Cut. On building
sites, in a wet environment, indoors and outdoors or under similar installation
conditions, only operate the electric pipe cutting machine on the mains with a
fault current protected switch (FI breaker) which interrupts the power supply
as soon as the leakage current to earth exceeds 30 mA for 200 ms.
Rechargeable batteries
844000 NOTICE NOTICE
844001
Always hold the battery (9) upright when inserting it in the drive unit or the rapid
844510
charger. If inserted at an angle it can cause damage to the contacts and result
571560
in a short circuit which damages the battery.
844050
Total discharging by undervoltage
844051
The Li-Ion batteries may not drop below a minimum voltage because otherwise
120120
the battery could be damaged by "total discharge". The cells of the ROLLER
120130
Li-Ion battery are delivered pre-charged to approx. 40 %. Therefore the Li-Ion
–10 °C – +60 °C (14 °F – +140 °F)
–10 °C – +60 °C (14 °F – +140 °F)
0 °C – +40 °C (32 °F – +104 °F)
220 – 240 V~; 50 – 60 Hz; 65 W
all-insulated, interference-suppressed
100 – 120 V~; 50 – 60 Hz; 65 W
all-insulated, interference-suppressed
405 × 90 × 103 mm (15.9"× 3.5"× 4.1")
408 × 88 × 105 mm (16.1"× 3.4"× 4.1")
= 78 dB(A) L = 67 dB(A) L
pA pC, peak
1.2 m/s² K = 1.5 m/s²
eng
120200
120240
574436
844045
Ø 12 – 28 mm
Ø 10 – 35 mm
Ø 10 – 40 mm
130 min‫¹־‬
1.9 kg (4.2 lb)
2.0 kg (4.4 lb)
0.2 kg (0.4 lb)
= 87 dB(A) K = 3 dB
