6
Index
1 Suction gauge blue
2 Pressure gauge red
3 adjustment
4 Low pressure port
5 High pressure port
6 Suction
7 Pressure valve
8 Refrigerant connection
Spare Parts for manifolds
Multi-Case
Gauge low pressure side
Gauge high pressure side
Complete valve
Gasket for CO2 manifold
Star handle low pressure blue
Star handle high pressure red
Threaded Y-style, 3 pieces
Set of charging hoses (3 pcs.)
1 3
4
3
8
M4-6-15
GR-420-DS-R744-80BAR
GR-520-DS-R744-160BAR
M2-10-Ventil
M2-10-Dichtung
M2-6-B-1
M2-6-R-1
A-31452-Y/3
CCL-72-DN6-R744-TC
2
7
5
Part No 4666106
Part No 4688385
Part No 4688386
Part No 4688848
Part No 4688849
Part No 4688874
Part No 4688875
Part No 4687951
Part No 4687906
7
