AWG | Fittings | Medium expansion foam nozzle M2, M4, M8
Versions
ID No .
602 516 99
603 516 99
603 141 99
602 518 99
603 517 99
603 732 99
604 003 99
This table lists the common Storz adapters.
Versions without adapters are marked "Anschluss BSP" (British Standard Pipe thread).
These devices are equipped with a pipe thread in accordance with ISO 228 that can be
used to mount further adapter systems.
For versions not listed in the table, the values for the BSP connection apply; the respecti-
ve adapter system is not taken into account.
4
Delivery, transport, storage
4 .1
Delivery
The Foam nozzle has been carefully packaged at AWG Fittings GmbH.
>
After unpacking, check the delivery for damage and verify completeness.
>
Any damage must be immediately reported to the carrier.
>
If parts are missing, immediately inform the responsible specialist
dealer or AWG Fittings GmbH.
The foam nozzle ýis delivered ready to be connected and is immediately
ready for use after connecting to a hose with a suitable adapter. No special
commissioning is required before first use.
29
Type
Connection
M2
Storz 52 (C)
M2
BSP G2" (male)
M4
Storz 52 (C)
M4
Storz 75 (B)
M4
BSP G2" (male)
M8
Storz 75 (B)
M8
BSP G2" (male)
DELIvERy, TRANSPORT, STORAgE
Dimensions [mm]
L
W
H
533
194
232
533
194
232
632
265
302
632
265
302
632
265
302
765
304
350
790
300
370
M1107B10 | Rev. 03-08/24
Weight
[kg]
3.6
3.4
4.8
5.6
4.7
7.5
6.1
