AWG M2 Originalbetriebsanleitung Seite 28

AWG | Fittings | Medium expansion foam nozzle M2, M4, M8
3 .4 Characteristic values
Flow rate at 5 bar
Foam coefficient
Effective foam throw distance
Recommended pressure range
Max. operating pressure
Operating temperature
3 .5 Overview
1
Hand lever (option)
2 Stop valve (option)
3 Pressure gauge 0 – 16 bar
4
Nozzle body
Fig. 1 Overview AWG Medium expansion foam nozzle
M1107B10 | Rev. 03-08/24
1
2
3
4
5
6
7
8
M2 M4
200 l/min 400 l/min
50 – 70 50 – 70
10 m
7 m
Approx. 3 to 5 bar
16 bar (PN16)
- 20 °C* to + 60 °C
* with running wate
1
2
3
4
5
6
7
5
Handle
6 Foam tube
7 Conversion screen
8
Protection ring (only M2, M4)
DESCRIPTION
M8
800 l/min
50 – 70
13 m
r
