ROTATING HORN (only for DVX DM12 and DVX DM15)
When used horizontally, the loudspeaker allow to maintain the same coverage angle
by featuring a rotating horn.
The speakers are always supplied by the manufacturer with the horn positioned horizontal
at 40°by default.
If you wish to change the coverage angle (FIG. 5):
- unscrew the fixing screws of the grille
- remove the front protective grille by slightly pressing on one side and taking the grille
off the recessed slots
- unscrew the eight fixing screws of the horn
- rotate the horn in the desired position (the horn should never be removed from the
driver!)
- tighten the fixing screws of the horn
- put the grille back in the recessed slots and tighten the screws of the grille.
LOUDSPEAKER INSTALLATION
WARNING
Make sure that the loudspeaker is securely installed in a stable position to avoid any
injuries or damages to persons or property.
For safety reasons do not place one loudspeaker on top of another without proper
fastening systems. Before hanging the loudspeaker check all the components for
damages, deformations, missing or damaged parts that may compromise safety during
installation.
If you use the loudspeakers outdoors avoid places that are exposed to bad weather.
The loudspeaker has the following mounting options:
- bookshelf (Fig. 1)
- on speaker stands (Fig.2)
- suspended with M8 eyebolts (only DM 12 and Dm15) (Fig.3)
WARNING
To hang the loudspeaker use only one eyebolt for each hanging point
The hanging points are of M8 threads.
Do not unscrew both bolts recessed in the housing!
WRONG!
