BSS Flow 8 Bedienungsanleitung Seite 17

BSS-Streaming Service
BSS-Flow 8 Case connections
The following connections on the BSS-Flow 8 Case are arranged in a user-friendly
way. Other connection sockets can be installed by selecting additional options.
Front panel
• On/off switch (A)
Right side
Left side
• Mains connection 230 V
• Version: C14 (F)
Rear panel
• USB-B socket (C)
Page 32
BSS-Flow 8 Case
A
B
C
Operating instruction EN
BSS-Flow 8 Case options
The following options on the BSS-Flow 8 Case are arranged on the back for ease of use.
Rear panel
• OPTION: Battery connection -
• XLR 4-pin (D)
• OPTION: USB-A charging socket
(E)
• USB-B socket (C)
• OPTION: L/R Cinch Out (unbal-
anced); galvanically isolated (F1-F2)
DOC-000044
DE
EN
D E
C F1-F2
Page 33
