8.6 Receiver with the EX Bus output
- suitable especially for connection to JETI model devices (such as
Central Box)
- EX Bus is present at Ext. receiver connector and the telemetry
sensors are then connected to the nearest EX Bus expander (e.g.
Central Box)
- after the receiver is switched on (with the transmitter turned off )
it is possible to connect JETIBOX to the receiver via Ext.
connector. After the transmitter is switched on, the serial
protocol on Ext. connector changes to EX Bus and the
configuration using connected JETIBOX is not possible until the
transmitter is switched off or the Rx mode is changed.
FailSafe
Enabled
8.7 Receiver with the UDI output
- suitable for connection of devices with unidirectional UDI
interface (e.g. VBar)
- UDI output is present on SAT2 output (if it exists), alternately
SAT1 (if it exists), alternately on the last servo output (then the
number of servo outputs is decreased by one) depending upon
your selected receiver
- the servo impulses are generated on other servo outputs, it is
possible to connect telemetry sensors to the Ext. connector as
usual
FailSafe
Enabled
