seconds elapse the receiver returns to setup mode and the binding
process must be repeated by starting again from step 3.
If the binding process between receiver and transmitter was
unsuccessful, try again.
You may bind an arbitrary number of receivers to one transmitter.
The receiver, however, can only be bound to one transmitter, i. e. the
receiver is only bound to the most recently bound transmitter.
Change since FW version 3.10!
As long as the BIND PLUG is inserted into Ext. input, the receiver is
always in „Normal" mode, regardless your actual receiver setup.
After BIND PLUG is removed, the receiver returns to your selected
setup mode.
3.4 Receiver R7nano
When soldering it is necessary to have the receiver disconnected
from the power. The receiver is a very sensitive device (ESD). We
recommend using soldering micro-iron. Beware of short circuits.
Beware of polarity. Reverse polarity of the receiver or servos
will cause their destruction. Use the power source with respect to
the servos used (5V or 7.4V for high voltage servos) and with respect
to the allowed receiver voltage (3.2-8.4V). The power can be
connected to any servo channel (1-7). Solder the servos to channels
1-7. The sensor or expander output can be soldered to the EXT
connector (labeled E). The function of individual pads is described
in the picture. Solder the black or brown wire to the minus (-). Solder
COMPLEX RADIO CONTROL SYSTEM
12
EN
